What are SR2 swing gates?
Can specify manual or powered/automated operation

SR2 swing gates are high-security entrance gates designed and manufactured by our own specialists and independently tested and verified as meeting LPCB standard LPS 1175 Issue 8.0 Security Rating SR2. The gates have been proven to resist a sustained attack using hand tools for a defined period of time and are listed in the LPCB Red Book as being SR2 security rated.

The Loss Prevention Certification Board (LPCB) is part of BRE Global, a third-party approvals body, and LPS 1175 is the internationally recognised standard for certification of intruder-resistant building components, strongpoints, security enclosures and free-standing barriers.

Enquireor call 0800 2944177

SR2 swing gates – product overview

Our SR2 swing gates come in single-leaf and double-leaf formats in a choice of widths and heights for securing pedestrians or vehicle access points. Customers can also specify manual or powered/automated operation, and we offer a variety of access control systems.

While our Pro-Secure SR1 swing gates provide good security, the SR2 single and double swing gates offer significantly higher security for only a small increase in cost. When tested against the LPS 1175 standard, the SR2 gates withstand a sustained attack using a broader array of tools and for a longer period. Furthermore, the gates’ internationally recognised SR2 security rating enables specifiers to demonstrate that they have performed due diligence in securing the site perimeter. This can prove invaluable for projects required to meet Secured by Design standards.

Compared with sliding gates, swing gates normally cost less and are often operated manually – which therefore avoids the costs of automation and the associated ongoing maintenance.

Installation normally requires just one day, so disruption at the site being secured is kept to an absolute minimum. Even when we are installing, commissioning and CE marking powered/automated gates, our skilled installation teams usually only need one day.

Downloads

    Download

      Download

        Download

          Download

          Key Features

          Applications

          Specification

          Security rating:LPCB standard LPS 1175 Issue 8.0 Security Rating SR2
          Heights:2.0 m to 3.6 m
          Opening widths:1.2 m to 5.0 m (single leaf) 2.0 m to 10.0 m (double leaf)
          Cladding:868 welded wire mesh, wire diameter 6 & 8mm, mesh size 200 mm x 50 mm 358 welded wire mesh, wire diameter 4 mm, mesh size 76.2 mm x 12.7 mm
          Materials of construction:Steel
          Hinges:Steel, adjustable
          Latch:As standard, sliding latch will be provided with an appropriate approved for heavy-duty padlock, but contact us with your requirements.
          Finish:Hot-dip galvanising with optional polyester powder coating in black, green or other RAL colours on request
          Compliance:Powered and automatic gates are CE Marked to the Machinery Directive
          Access control system:Contact us to discuss options
          Guarantee:The system comes with 12 months warranty
          MaintenanceMaintenance programmes are available which reduces the chances of equipment failure and any health and safety issues.

          What are the key features of SR2 swing gates?

          All-steel construction makes our SR2 swing gates more robust than gates fabricated from other materials, and the mesh used for the cladding provides excellent anti-climb and anti-cut characteristics. The SR2 security rating applies to gates in a variety of heights and widths, so we can supply high-security gates for a variety of different applications. Detailed design features that help the gates achieve their coveted SR2 certification include high-security mesh cladding, hinge protection plates and reinforced latch areas.

          Each gate leaf has a framework fabricated from heavy-gauge RHS (rectangular hollow section) steel, braced as necessary. Robust twin-wire 868 wire mesh is fully welded into the frame to ensure there are no weak points. The 868 mesh is then double-clad with heavy-duty 358 anti-cut, anti-climb mesh that is attached using clamp bars, security bolts and shear cone nuts. The combination of 868 mesh and 358 mesh provides excellent resistance to cutting and climbing while still providing visibility for CCTV systems and security patrols.

          All steel parts are hot-dip galvanised for long-lasting resistance to corrosion and we can optionally apply a tough polyester powder coat on top of the galvanising for further protection and improved aesthetics. Our standard colours are black and green but customers can specify almost any other RAL colour.

          Hot-dip galvanising is in accordance with BS EN ISO 1461 (Hot dip galvanized coatings on fabricated iron and steel articles – Specifications and test methods) and powder coating complies with BS EN 13438 (Paints and varnishes – Powder organic coatings for hot-dip galvanised or sherardized steel products for construction purposes).

          With their robust construction and anti-corrosion finish, SR2 swing gates require little or no maintenance over their long lifetime. Note, however, that powered/automated gates should be inspected periodically to ensure continued safe and reliable operation. For customers wanting regular inspections, we offer maintenance contracts or, if the gates are damaged during use, we can repair them on-site at short notice or at our factory.

          Our work

          Procter Contracts is part of Procter Bros Ltd, a family-owned and run company with a history dating back more than 275 years. We have over a century of experience in the perimeter security market and have earned a reputation for the high quality of our products and exceptional standards of customer service. You can, therefore, be confident that we have the knowledge and experience to meet your requirements for SR2 security-rated swing gates.

          We always use our own teams of highly skilled installers, not casual labour, which enables us to guarantee the quality of the installation. Procter Contracts has the following accreditations:

          • Secured by Design accredited installer of fencing and gates
          • dhf (Door and Hardware Federation) Safety Assured installer for powered and automatic gates
          • Gate Safe Aware Installer for powered and automatic gates
          • Full Member of PSSA (Perimeter Security Suppliers Association)
          • In addition, we hold a number of accreditations for working on-site as a contractor.

          Find out more
          If you would like to know more about our SR2 single or double swing gates, download our literature or contact us to discuss your project.

          Other types of security-rated gate

          We also offer other types of security-rated gates if our SR2 swing gates are not suitable for your application. Follow the links for more information about our Pro-Secure SR1 swing gates, SR1 sliding gates or SR2 sliding gates.
